2023 Ford F-150 Towing Capacity

The Ford F-150 towing capacity has always been ahead of any vehicle in its class, and that doesn't change with the latest model. What is the towing capacity of a Ford F-150 for 2023? The 2023 Ford F-150 towing capacity reaches an astounding 14,000 pounds! What else can North Tonawanda expect from the latest version of this iconic pickup truck?

Take a look at the F-150 payload capabilities and towing power in more detail with the team at Basil Ford of Niagara Falls. Then, make the drive to our dealership to give any Ford F-150 model in our inventory a test drive, so you can get a glimpse of just how powerful this pickup truck truly is.

F-150 Towing & Payload Capacity by Engine Option

The Ford F-150 towing capacity tops off at 14,000 pounds, but how much can you put in the back of the vehicle? The 2023 Ford F-150 payload capacity maxes out at 3,315 pounds when paired with the right engine. While these are the maximums, the performance capabilites of the Ford F-150 vary by engine since there are so many different options. Take a look at the variances in performance for each engine option:

3.3L Ti-VCT V6 Engine

• Up to 290 horsepower
• Up to 265 lb-ft of torque
• Maximum towing capacity of 8,200 pounds
• Maximum payload capacity of 1,955 pounds

2.7L EcoBoost® V6 Engine

• Up to 325 horsepower
• Up to 400 lb-ft of torque
• Maximum towing capacity of 10,000 pounds
• Maximum payload capacity of 2,465 pounds

5.0L Ti-VCT V8 Engine

• Up to 400 horsepower
• Up to 410 lb-ft of torque
• Maximum towing capacity of 13,000 pounds m
• Maximum payload capacity of 3,315 pounds

3.5L EcoBoost® V6 Engine

• Up to 400 horsepower
• Up to 500 lb-ft of torque
• Maximum towing capacity of 14,000 pounds
• Maximum payload capacity 3,235 pounds

3.5L PowerBoost™ Full Hybrid V6 Engine

• Up to 430 horsepower
• Up to 570 lb-ft of torque
• Maximum towing capacity of 12,700 pounds
• Maximum payload capacity of 2,120 pounds

High-Output 3.5L EcoBoost® Engine

• Up to 450 horsepower
• Up to 510 lb-ft of torque
• Maximum towing capacity of 8,200 pounds
• Maximum payload capacity of 1,385 pounds

High-Output Supercharged 5.2L V8 Engine

• Up to 700 horsepower
• Up to 640 lb-ft of torque
• Maximum towing capacity of 8,200 pounds
• Maximum payload capacity of 1,440 pounds

Ford F-150 Towing Packages

To achieve the maximum Ford F-150 towing capacity of 14,000 pounds on the roads of Grand Island, you'll need to equip your F-150 with the Max Trailer Tow Package. Additionally, you'll need the Heavy-Duty Payload Package to be able to reach the maximum Ford F-150 payload capacity.

What do these packages entail besides maxing out the towing and payload capabilities of the Ford F-150? Here are some of the highlights of the Max Trailer Tow Package:

Max Trailer Tow Package

• 36-gallon fuel tank (not available with the 3.5L PowerBoost or 3.0L diesel engine)
• Class IV trailer hitch receiver
• Pro Trailer Backup Assist™
• 3.55 electronic-locking rear axle (axle is changed to 3.73 electronic-locking differential when paired with the Heavy-Duty Payload Package)
• 4-pin/7-pin wiring harness
• Upgraded rear bumper
• Smart Trailer Tow Connector (includes BLIS® with Trailer Tow Coverage where BLIS® is available)

Heavy-Duty Payload Package

• Upgraded springs
• LT265/70R18C OWL all-terrain tires (A/T)
• 18-inch silver aluminum Heavy-Duty Payload Package wheels
• 3.73 electronic-locking rear axle
• 9.75-inch gearset
• 36-gallon fuel tank

So, what is the towing capacity of a Ford F-150? The maximum amount is 14,000 pounds, but depending on what your driving needs are around Lockport, you may be more inclined to choose an engine that provides less towing power and more fuel efficiency. The best way to decide which Ford F-150 engine and trim is right for you is to visit Basil Ford of Niagara Falls and take it for a test drive.

Experience the Ford F-150 at Basil Ford of Niagara Falls

To see how the Ford F-150 towing capacity and payload capabilities can help you take on heavy-duty jobs around Niagara Falls, contact us. We'll show you around our available inventory and even help you apply for financing, so you can get one step closer to your dream Ford F-150.
